• • Corrosion resistant internals make it compatible with all known fuels, capable of extended service life with corrosive fuels.
  • Compact body allows fitment in 200+ applications, including current and future engines utilizing short body injectors
  • Improved internal flow path increases output by 5% without sacrificing low flow performance.
  • Stronger magnetic circuit offers stable operation up to 10 bar.
  • Replaceable inlet filter extends service life.


    ID1050-XDS Dynamic Flow Data

    Fuel Pressure			Offset			Slope
    (psid)			(µsec)			(cc/min)
    	8 Volts	10 Volts	12 Volts	14 Volts	16 Volts
    40.0	1920	1410	1115	920	790	1020
    43.5	1955	1425	1125	925	795	1065
    45.0	1970	1435	1130	930	800	1085
    50.0	2025	1475	1160	955	825	1145
    55.0	2080	1515	1190	980	845	1205
    60.0	2140	1540	1215	1000	860	1260
    65.0	2195	1560	1225	1010	855	1305
    70.0	2255	1575	1235	1015	850	1350
    75.0	2340	1610	1250	1020	850	1390
    80.0	2440	1655	1265	1020	850	1420
    85.0	2555	1705	1280	1030	855	1455
    90.0	2680	1765	1315	1045	865	1490
    95.0	2815	1825	1355	1075	880	1530
    100.0	2960	1890	1405	1110	900	1565

  • ID1700x is the most recent offering from the partnership of Injector Dynamics and Bosch MA unique magnetic circuit, resulting from a lengthy development program, makes the ID1700x immune to voltage and pressure sensitivity problems that plague other high impedance high flow injectors. The ID1700x excels at high pressures typical of current automotive systems, and will perform flawlessly in these applications.ID1700-XDS Dynamic Flow Data

  • ID1300x² is an all new injector, designed in partnership with Bosch Motorsport. This collaboration has given us the ability to design a high flow injector with characteristics specific to the needs of the motorsport tuner. The ID1300x² was designed with alternative fuels in mind, and was originally the only performance injector available with all stainless internals. It is compatible with all known fuels, and will stand up to the corrosive nature of alcohol better than any injector on the market.
    While the ID1300x² was designed with an eye towards ethanol fueled engines, we have accounted for the occasional need to convert back to gasoline. The ID1300x² has a minimum fuel mass compatible with gasoline use, and will provide exceptional idle and cruise behavior under these conditions. In addition to its multi-fuel capabilities, the compact body of the ID1300x² allows fitment in 200+ applications, making it the most versatile injector in our lineup.

    ID1300-XDS Dynamic Flow Data

  • Fuel Pressure			Offset			Slope
    (psid)			(µsec)			(cc/min)
    	8 Volts	10 Volts	12 Volts	14 Volts	16 Volts
    40.0	2175	1575	1235	1020	855	1275
    43.5	2230	1610	1255	1035	865	1335
    45	2255	1620	1265	1040	870	1360
    50	2350	1665	1290	1055	880	1440
    55	2445	1715	1320	1070	895	1520
    60	2535	1765	1355	1095	915	1590
    65	2620	1830	1395	1125	935	1655
    70	2705	1895	1445	1160	960	1715
    75	2790	1955	1480	1185	975	1770
    80	2875	2015	1510	1205	990	1820
    85	N/A	2075	1540	1220	1005	1860
    90	N/A	2135	1580	1250	1025	1895
    95	N/A	2195	1625	1280	1050	1925
    100	N/A	2250	1675	1320	1080	1950

  • otorsport. The ID1700x was designed to fill the gap between the ID1300x and the ID2000, and like the ID1300x, it features corrosion resistant internals making it compatible with all known automotive fuels.

  • Fuel Pressure			Offset			Slope
    (psid)			(µsec)			(cc/min)
    	8 Volts	10 Volts	12 Volts	14 Volts	16 Volts
    43.5	2745	1740	1260	975	800	1725
    45.0	2805	1760	1275	980	805	1760
    50.0	3050	1835	1320	1020	830	1855
    55.0	3330	1915	1375	1065	855	1950
    60.0	3610	2000	1430	1110	885	2040
    65.0	3895	2090	1490	1150	920	2125
    70.0	N/A	2180	1545	1195	960	2205
    75.0	N/A	2270	1605	1235	995	2285
    80.0	N/A	2365	1670	1275	1025	2360
    85.0	N/A	2455	1730	1315	1055	2435
    90.0	N/A	2555	1785	1355	1085	2505
    95.0	N/A	N/A	1845	1400	1120	2575
    100.0	N/A	N/A	1900	1440	1155	2640

Not compatible with OEM Fuel System; must use Port Injection Kit.

BMW S58 Applications:

2 Series

2023-Present     G87     M2

3 Series

2021-Present     G80     M3

4 Series

2021-Present     G82/G83     M4

X3 Series

2019-Present     F97     X3M

X4 Series

2019-Present     F98     X4M
